| Pharmaceutical granulate dryer Hogner |
|
Pharmaceutical drying oven.
Brand: Hogner.
Model: Dryer 8001 E / SP Anti-explosive.
Year: 2009.
Tray dimension: 880 mm x 880 mm x 40 mm (Width x Length x Height).
Width: 980 mm.
Height: 1750.
Depth: 1,000 mm.
Volume: 1715 m³.
Voltage: 3 x 220 VAC.
Frequency: 60 hz.
With space for 31 trays.
NBR ISO / IEC calibration made by Mec-Q.
Calibration date: 08/02/2018.
Next calibration date: 2/28/2019.
Components:
Saia-Burgess Electronics.
Modelo: Saia PCD1.M1.
Phoenix Contact.
Telemecanique.
Schneider.
Danfoss.
Festo.
With door internal part in 316 L stainless steel, outside in 304 stainless steel polished.
With hermetic system for high temperature.
Chamber:
Constructed entirely in 316L stainless steel sheets, with polishing.
With good homogenization of temperature.
With antechamber of inspection.
Easy disassembly for cleaning.
Panel:
Equipped with industrial microprocessor and monochrome touch screen control panel, with function to view all the
operator-friendly settings.
Allows programming for up to 99 cycles.
Programmable for the variables of each cycle.
Entry for validation.
In front of the equipment is the entrance to enter the temperature sensors for thermal validation (TF).
Silicon-tight stainless steel clamp connection.
Depending on the size of the sensors, more than 12 can be used inside the camera.
With emergency stop button.
With thermal printer protected by cover, to print up to forty characters.
With audible alarm. |
Brand:
Almapal, Hogner
|
Components:
Danfoss, Festo, Phoenix Contact, Saia-Burgess, Schneider, Telemecanique
|
|
|
|
