 Jacketed tank
Main brands:
, Apema, APV, Brasholanda, Consolid, Globoinox, Imarvil, Incal, Incomar, Inoxil, Kroma, Max Machine, RDS INOX, Ricefer, Rodrinox, Tersainox, Topp Inox, Vonin, Zegla
|
| Jacketed tank |
A jacketed tank is a type of vessel or reactor used in industrial and chemical processes that has a "jacket" around its outer wall. This "shirt" is an empty space between the inner wall of the tank and the outer wall, usually filled with a fluid, such as water or oil. Jacketed tanks have several applications and benefits, including:
Temperature Control: The jacket around the tank allows for precise control of the temperature of the contents within the tank. The fluid in the jacket is heated or cooled, influencing the temperature of the material inside the tank. This is particularly important in chemical and pharmaceutical processes where the temperature needs to be maintained within strict limits.
Efficient Heating and Cooling: The jacketed jacket provides an efficient method of heating or cooling the tank contents, ensuring even temperature distribution.
Maintaining viscosity: In some applications, maintaining the viscosity of the material within the tank is crucial. Precise temperature control helps maintain ideal viscosity for the process.
Controlled chemical reactions: In chemical reactors, jacketed tanks allow operators to control the temperature during chemical reactions, ensuring the safety and effectiveness of the process.
Prevent overheating: In processes where overheating of the tank contents could be harmful or dangerous, the jacketed liner helps to avoid this problem.
Refrigeration of heat-sensitive products: In industries such as food and beverage, where heat-sensitive products such as juices or syrups are processed, the jacket helps to quickly cool the product after pasteurization or other heat treatments.
In summary, jacketed tanks are used in a variety of industries to control temperature and maintain specific conditions during production processes, chemical reactions, and product storage. They play a fundamental role in ensuring the quality and safety of industrial products and processes.
Check out jacketed tank options for sale: |
|
|
|
 |
Brand: Ricefer
Jacketed tank for electric heating.
Brand: Ricefer.
With electric heating system, two resistances.
With control panel, frequency inverter for motors, temperature control by sensor in the tank.
Two stirring systems.
Main system with sid... |
|
|
 |
Jacketed stainless steel funnel tank with heating system.
It has a conical bottom.
For flowing liquids.... |
|
|
 |
Brand: Consolid
Jacketed reactor with stainless steel resistance heating for laboratory.
Manufacturer/brand: Consolid.
Year: 2011.
Test pressure: 3 kgf / cm².
Maximum permissible working pressure: 2 kgf / cm².
Useful volume: 1.5 liters.
Total volum... |
|
|
 |
Components: WEG
Jacketed tank for melting chocolate in stainless steel.
Melting tank for chocolates.
Approximate capacity: 170 liters.
Electric resistance heating in the jacket.
Engine: WEG 1 CV.
It has a split lid.
With analog temperature controll... |
|
|
 |
Components: WEG
Mixer reactor tank jacketed in stainless steel.
Approximate capacity: 170 liters.
Electric resistance heating in the jacket.
Engine: WEG 1 CV.
It has a split lid.
Unused tank.... |
|
|
 |
Insulated stainless steel tank.
Brand: Stainless.
Capacity: 2,000 kg.
Approximate measurements: 2.12 height
Approximate 1.19 diameter.... |
|
|
 |
Brand: Rodrinox
Components: WEG
Open reactor tank for mixing and homogenizing products.
Brand: Rodrinox.
With 3 stirring systems.
Mixing system 1
With motor and reducer, side and lower blades and scrapers.
2 mixing system.
With motor and reducer with 3 helix on th... |
|
|
 |
Components: WEG
Stainless steel pressure reactor.
Capacity: 1,100 L.
Jacked tank.
With motor, reducer, shaft and propeller.
Extra space for inserting accessories, bottom (with black screw-on cover photo 20)
304 stainless steel.
Conical bottom.
O... |
|
|
 |
Brand: Zegla
Storage tank in stainless steel.
Capacity: 7,500 L.
With thermal insulation.
With agitator on the bottom, motor on the side.
Brand: Zegla.
Engine brand: Eberle.
Outlet of the product at the bottom of the tank, with valve operated by... |
|
|
 |
Tank insulated with refrigeration, internal in stainless steel and external in carbon steel.
Capacity of 1,300 liters.... |
|
|
 |
Stainless steel tank with internal cooling like tina.
220 litres capacity.... |
|
|
 |
Components: Alfa Laval, SEW-Eurodrive, Tretalon
Sanitary stainless steel mixing tanks.
With spray ball system attached.
Year: 2011.
It has a double helix.
It has a protective window and supports vacuum.
Reducer: Sew Eurodrive.
Weight: 500 kg.
Quantity: in confirmation.
2 u... |
|
|
 |
Jacketed tank for chocolates.
Internally in stainless steel.
Approximate capacity: 2190 liters.
Approximate dimensions:
Tank Height: 1.70 m.
Total Height: 2.20 m.
Diameter: 1.28 m.
Main outlet pipe diameter (bottom): 55 mm.
Wi... |
|
|
 |
Internal stainless steel jacketed tank for chocolates.
Approximate capacity: 750 liters.
Approximate dimensions:
Total Height: 2.05 m.
Tank Height: 1.55 m.
Diameter: 790 mm.
Main outlet pipe diameter (bottom): 55 mm.
Without moto... |
|
|
 |
Cooking pot for sweets.
Capacity: 1,500 kg.
With steam jacket with 3 heating zones.
Reducer at the bottom of the pan.... |
|
|
 |
Jacketed tank for 1,500 L.
It was once used as a tank to melt chocolates.
Carbon steel equipment.
Steam circulation.
Dimensions:
Diameter: 2 M.
Height: 2.20 m
Total height: 2.50 m.... |
|
|
 |
2 jacketed Tanks for reception of fat to 10 tons each.
internal finish in carbon steel insulated.... |
|
|
 |
Jacketed tank 5000 litres for chocolate-carbon steel.... |
|
|
 |
Insulated jacketed maturation tanks.
- Stainless steel tank.
Approximate capacity: 3000 liters. (UNAVAILABLE)
- Tank in carbon steel externally and internally in stainless steel.
Approximate capacity: 2000 liters.
For maturing ice cre... |
|
|
 |
Tanks silos jacketed of 20.000 liters each.
It was used for glucose storage.
Tapered bottom: 1.50 m.
Diameter: 2.20 m.
Feet: 2.58 m
Overall length without feet: 5.70 m.
Total length with feet: 8.40 m approximately (because there is ... |
|
|
 |
Stainless steel jacketed tank 1000 litres.... |
|
|
 |
Tank for 2,000 liters.
Internal jacketed tank in stainless steel.
External carbon steel
Note: Equipment missing motorbike and agitator set.... |
|
|
 |
Stainless steel tank.
Capacity: 4,000 L.
Isolated.
with 7.5 hp engine.
With stirrer and motor.
With emulsion system.
Diameter 1.70 m x 1.75 m high.... |
|
|
 |
Resistance heating jacketed storage tank.
Approximate capacity: 4800 liters.
In carbon steel with motor, reducer and agitator.
Approximate measurements:
Outside diameter: 2200 mm.
Inner diameter: 1850 mm.
Internal height: 1800 mm.
... |
|
|
 |
Brand: Tersainox
Tank for fermentation of wines and beverages.
Manufacturer: Tersainox.
Volume: 5,000 L.
Model: FPP 1817.
Quantity: 4 equal tanks.
Year: 2009.... |
|
|
 |
Brand: Kroma
Infuser jacketed mixing tank.
Useful capacity: 1,200 L.
Manufacturer brand: Kroma special equipment.
Year: 2020.
Infusion tank for syrups and infusions.
Product: syrups and infusions
Maximum Density Considered: 1,000 Kg/m³
Maximu... |
|
|
 |
Industrial boiling tank for drinks and food.
Brand: Kinox.
Capacity: 500 L.
Tina service and support platform
Control panel brazing 500 liters.
Two stage 1 M³ / H plate cooler.
Steam and condensate pipes and insulation
Cold syste... |
|
|
 |
Components: Alfa Laval
316 L stainless steel reactor with internal electrostatic polishing.
For viscous products.
For batches up to 12 tons, depending on the product density.
Internal part stainless steel 316 L electrostatic polishing.
Model: RD 100 - P120 - 15... |
|
|
|
|
