Spray Dryer Galaxie product drying system
>> Spray Drying
|
|
|
|
|
| Spray Dryer Galaxie product drying system |
|
Spray Dryer Product Drying System.
Manufacturer | Brand: Galaxie.
Model: 5058.
Year of manufacture: 2005.
Approximate evaporation: up to 750kg / h.
Feed concentration: 30 - 50 % ST.*
*depending on the product.
Feed temperature: ambient.
Installed power (hp): 135.
Natural gas (nm3 / h): 120.
Compressed air (nm3 / h): 2.
Composed of:
- Product feeding system consisting of a feeding tank, a feeding pump, a basket filter, a supply tube and a centrifugal atomizer rotor.
The feeding pump is new. Positive for screw. Body H ° F ° and rotor
Buna N. Built in SS 316 in all parts in contact with the product. Danish threaded connections. Powered by a standard three-phase electric motor reducer.
The filter is of the basket type. Constructed of SS 304.
The supply pipe: New. From the feed tank to the atomizer rotor. Constructed of SS 304. Standard accessories. With support for equipment and / or metal structure.
The centrifugal atomizer rotor is used, reconditioned. A general maintenance service will be carried out, with replacement of bearings, oil, belt and overhaul of the electric motor.
- Spray Dryer of drying chamber, consisting of spray chamber, a beating system with pneumatic hammers and a ceiling cooling fan and rotor.
The spray chamber is new. Diameter 5800 mm. Conical bottom at 60 °. Constructed of 3 mm thick sheet metal, stainless steel quality SS 304, with cloths for easy transfer. Includes access door for inspection and cleaning. Exterior reinforcements in painted carbon steel profiles. Prepared to be thermally insulated on site by the importer.
The pneumatic hammer striking system is new. Quantity: 7. Composed of a buffer tank, pneumatic hammer, electro-actuation valve, programmer to control the impact frequency, FRL and pneumatic installation of the FRL.
The ceiling cooling fan and rotor are used reconditioned. Centrifugal type. Constructed of carbon steel. Powered by a standard three-phase electric motor.
- Air heating system, with direct furnace, burner and hot air duct.
The direct furnace is used reconditioned. Constructed of SS 304. Prepared to be thermally insulated on site by the importer.
The burner is used reconditioned with the manufacturer | Mettler brand with a capacity of approximately 1,200,000 kcal/h. Suitable for working with Natural Gas. Manual control, with valve train, safety system, combustion air fan and flame detection.
The hot air duct is used and reconditioned. Constructed in SS 304. Prepared to be thermally insulated on site by the importer.
- Air separation system - dust, consisting of chamber - cyclone duct, cyclone separator, cyclone fan duct - exhaust, exhaust fan, rotary valve, cyclone discharge duct and chimney.
The chamber - Cyclone Duct is used, reconditioned. Constructed in SS 304.
The cyclone separator is used, reconditioned. Constructed in SS 304. General cleaning and replacement of gaskets and screws. Revision of interior and exterior polishing.
The Cyclone-Exhaust fan duct is used, reconditioned. Constructed in SS 304. General cleaning and replacement of gaskets and screws. Revision of interior and exterior polishing.
The exhaust fan is used, reconditioned. Made of SS 304. New electric motor and transmission belts.
The rotary valve is used and reconditioned. Body and rotor in SS 304 quality stainless steel. Driven by a standardized three-phase electric motor and chain transmission. Rotor mounted on bearings in side covers. Closures by standard seals.
The cyclone discharge duct is new. Made of SS 304. Removable for cleaning. Industrial exterior polishing.
The chimney is new, in carbon steel. Length: 10,000 mm. |
